Engine
Engine Type
Liquid-cooled, 4-stroke Parallel Twin
Displacement
649
Bore x stroke
83 x 60 mm
Compression ratio
10:8:1
Valve/Induction system
DOHC, 8 valves
Fuel system
Fuel injection: 38 mm x 2 with sub-throttles
Ignition
Digital
Starting
Electric
Lubrication
Forced lubrication, semi-dry sump
CO2 Emission
102 g/km
Frame
Frame type
Tubular diamond, high-tensile steel
Rake/Trail
2,310 x 880 x 1,100 mm
Wheel travel
Front: 130mm / Rear: 80mm
Seat Height
705mm
Curb Mass
229kg
Ground Clearance
130mm
Performance
Maximum Power
44.7 kW {61 PS} / 7,500 rpm
Maximum torque
62.4 N•m {6.4 kgf•m} / 6,600 rpm
Transmission
Transmission
6-speed
Final Drive
Sealed chain
Clutch
Wet multi-disc, manual
Brakes
Brakes Front
Front: Single 300 mm disc. Caliper: Dual-piston / Rear: Single 250 mm disc. Caliper: Single-piston
Suspension
Suspension front
41 mm telescopic fork
Suspension Rear
Offset laydown single-shock, linkage equipped, with 7-way adjustable preload
Dimensions
Dimensions (L x W x H)
2,310 x 880 x 1,100 mm
Wheelbase
1,575 mm
Fuel Capacity
14 litres
