Engine
Engine Type
Liquid-cooled, 4-stroke In-Line Four
Displacement
948
Bore x stroke
73.4 x 56 mm
Compression ratio
11.8:1
Valve/Induction system
DOHC, 16 valves
Fuel system
Fuel injection: Ø 36 mm x 4 with sub-throttle
Ignition
Digital
Starting
Electric
Lubrication
Forced lubrication, wet sump
CO2 Emission
117 g/km
Frame
Frame type
Trellis, high-tensile steel
Rake/Trail
Trail: 110mm
Wheel travel
Front: 120 mm | Rear: 140 mm
Steering angle
33° / 33°
Seat Height
830 mm
Curb Mass
214 kg
Ground Clearance
145 mm
Performance
Maximum Power
91.0 kW {124 PS} / 9,500 rpm
Maximum torque
97.4 N•m {9.9 kgf•m} / 7,700 rpm
Transmission
Transmission
6-speed, return
Final Drive
Chain
Clutch
Wet multi-disc, manual
Brakes
Brakes Front
Dual semi-floating 300 mm Brembo discs. Caliper: Dual radial-mount, Brembo M4.32 monobloc, opposed 4-piston
Brakes Rear
Single 250 mm disc. Caliper: Single-piston
Suspension
Suspension front
41 mm inverted fork with compression and rebound damping and spring preload adjustability
Suspension Rear
Horizontal Back-link, Öhlins S46 gas-charged shock with rebound damping and spring preload adjustability
Dimensions
Dimensions (L x W x H)
2,065 x 830 x 1,075 mm
Wheelbase
1,450 mm
Fuel Capacity
17 litres
