Engine
Engine Type
Liquid-cooled, 4-stroke Parallel Twin
Displacement
649
Bore x stroke
83 x 60 mm
Compression ratio
10.8:1
Valve/Induction system
DOHC, 8 valves
Fuel system
Ø 36 mm x 2 with dual throttle valves
Ignition
Digital
Starting
Electric
Lubrication
Forced lubrication, semi-dry sump
Frame
Frame type
Trellis, high-tensile steel
Seat Height
805mm
Curb Mass
190 kg* | *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
Ground Clearance
130 mm
Performance
Maximum Power
50.2 kW {68 PS} / 8,000 rpm
Maximum torque
64 N•m {6.5 kgf•m} / 6,700 rpm
Transmission
Transmission
6-speed
Final Drive
Chain
Clutch
Wet multi-disc, manual
Brakes
Brakes Front
Dual semi-floating 300 mm petal discs. Caliper: Dual piston
Brakes Rear
Single 220 mm petal disc. Caliper: Single-piston
Suspension
Suspension front
41 mm telescopic fork
Suspension Rear
Horizontal Back-link with preload adjustment
Dimensions
Dimensions (L x W x H)
2,055 x 805 x 1,080 mm
Wheelbase
1,410 mm
Fuel Capacity
15 Litres
