The Panigale twin flaunts a simple design and clear-cut lines, with sophisticated electronics that make it equally high-performance and enjoyable on both road and track. The new Black on Black livery transmits power at first glance, as well as even more audacious style.
A simple design with clear-cut lines that convey power, without compromising classic Ducati superbike flair. The Panigale V2 features the single-sided aluminium swingarm, the hallmark of every high-end sports Ducati. The extensive fairing envelopes the refined monocoque frame, highlighting a more compact Superquadro twin-cylinder engine, smaller in comparison to the Desmosedici Stradale.
A main fairing extends upwards and merges into the tank with its muscular shoulders, while a secondary layer serves as an air vent. This 'double layer' solution revives the clean lines typical of Ducati sports bikes, famed for their full-fairing look. The fairing underside is visually connected to the under-engine silencer, which terminates in a single lateral pipe.
Frame
Frame
Monocoque Aluminium
Rake
24 Degrees
Front Wheel
5-spokes light alloy 3.50" x 17"
Front Tyre
Pirelli Diablo Rosso Corsa II 120/70 ZR17
Rear Wheel
5-spokes light alloy 5,50” x 17”
Rear Tyre
Pirelli Diablo Rosso Corsa II 180/60 ZR17
Fuel Tank Capacity
17 L
Dry Weight
176kg
Performance
Engine Type
Superquadro: L-twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled
Displacement
955cc
Power
114 kW (155 hp) @ 10.750 rpm
Torque
104 Nm (76,7 lb-ft) @ 9.000 rpm
Exhaust
2-1-2-1 system, with 2 catalytic converters and 2 lambda probes
Gearbox Type
6 speed with Ducati Quick Shift (DQS) up/down EVO 2
Gearbox Ratio
1=37/15 2=30/16 3=27/18 4=25/20 5=24/22 6=23/24
Primary Drive
Straight cut gears; Ratio 1.77:1
Final Drive
Chain; Front sprocket 15; Rear sprocket 43
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch
Brakes
Front Brake
2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston callipers with Cornering ABS EVO
Rear Brake
245 mm disc, 2-piston calliper with Cornering ABS EVO
Suspension
Front Suspension
Fully adjustable Showa BPF fork. 43 mm chromed inner tubes
Rear Suspension
Fully adjustable Sachs unit. Aluminum single-sided swingarm
Dimensions
Wheelbase
1.436 mm (56, 5 in)
Front Wheel Travel
120 mm (4.72 in)
Rear Wheel Travel
130 mm (5.12 in)
Seat Height
840 mm (33,1 in)
Bore x Stroke
100 x 60.8 mm
Compression Ratio
12.5:1
