Colour Options UK
Metallic Diablo Black - £24,649.00
Available from November 2023
Add accessories to this model by selecting them below.
Helmet lock kit
£108.95
Smoke windshield
£79.95
Rider ERGO-FIT™ Low seat (-15mm)
£209.95
Akrapovic titanium sports exhaust
£1,694.95
Ninja H2 SX Pannier system
£846.75
Universal Phone Clutch Mount Kit - M6
£126.95
Oil filler cap
£33.95
Frame slider set
£187.95
Engine
Engine Type
Liquid-cooled, 4-stroke In-Line Four with Supercharger
Displacement
998 cm3
Bore x stroke
76 x mm
Compression ratio
11.2:1
Valve/Induction system
DOHC, 16 valves
Fuel system
Fuel injection: O 40 mm x 4 with dual injection
Starting
Electric
Lubrication
Forced lubrication, wet sump with oil cooler
Frame
Frame type
Trellis, high-tensile steel with Swingarm Mounting Plate
Rake/Trail
103 mm
Wheel travel
Front - 120 mm, Rear - 139 mm
Seat Height
835mm
Curb Mass
267kg
Performance
Maximum torque
137.3 N•m {14 kgf•m} / 8,500 rpm
Transmission
Transmission
6-speed, dog-ring
Final Drive
Sealed chain
Clutch
Wet multi-disc, manual
Brakes
Brakes Front
Dual semi-floating 320 mm discs. Caliper: Dual radial-mount, monobloc, opposed 4-piston
Suspension
Suspension front
43 mm inverted fork with KECS-controlled rebound and compression damping, manual spring preload adjustability, and top-out springs
Suspension Rear
New Uni Trak, BFRC lite gas-charged shock with piggyback reservoir, KECS-controlled compression and rebound damping, and electronically adjustable spring preload
Dimensions
Dimensions (L x W x H)
2,175 x 790 x 1,260 mm
Wheelbase
1,480 mm
